Plans, elevations & renderings
A selection of recent residential drafting work, organized by project. Select any image to view it larger.
Residential Permit Set
A permit-ready plan set for a single-story home with a new addition, front porch and deck — exterior elevations, foundation and floor plans, and a building section with typical construction notes.
Pole Barn with Mezzanine
A post-frame pole barn with two overhead doors and an interior mezzanine — a color rendering plus the main level plan, building sections and mezzanine plan.
Lake Home Remodel / Addition
A remodel and addition for a two-story lake home with a new deck, stairs, sunroom and updated layout — a color rendering, exterior elevations and new floor plans.
Six-Unit Townhome Building
A full plan set for a two-story, six-unit townhome building laid out as three mirrored pairs, each unit with its own garage, main-level living space and three bedrooms upstairs — a color rendering, cover sheet notes, exterior elevations, main level plans and building sections.
